HySecurity SlideDriver 15 UPS | HYS-222-DS-ST

Note: This product has been discontinued and is no longer available.
It has been replaced by the new SlideDriver II SD15, offering improved performance and updated features.

SlideDriver is a powerful, industrial hydraulic slide gate operator that secures industrial and crash sites worldwide. This rugged, continuous-duty operator is renowned for decades-long life and low maintenance.

The Uninterruptible DC Power Supply provides up to 3,000 ft (914 m) of gate travel after AC power loss.* Available in single phase only: Low voltage: 115V 60/50Hz (requires 30A branch circuit) or High voltage: 208-230V 60/50Hz (requires 15A branch circuit). Be certain to order the correct HyCharger DC™ voltage model as chargers are not field convertible. UPS model uses 2 hp 24VDC motor.

Note: Includes one premium EMX IRB-MON photo eye and one 5-foot premium ASO edge sensor (and a pre-wired Hy2NC adapter).

Note: Please note that all operators come in 60 Hz. If you need an operator with 50 Hz, please call us at (800)-730-8382 for a special order.

Features

• Move the longest, heaviest gates up to 20,000 lbs.
• DC Power Supply (UPS): Uninterruptible Power Supply provides a minimum of 3,000 ft (914 m) of gate travel using 24VDC batteries.

Operator Components

Model: SlideDriver 15 UPS

• Part Number: 222 DS ST
• Est. Ship Weight: 243 lb
• Shipping Dimensions: 26"w x 30"d x 35"h
• Shipping Class: 70

Model: DC Power Supply 60

• Part Number: DCPS-60
• Est. Ship Weight: 335 lb
• Shipping Dimensions: 39"w x 28"d x 39"h
• Shipping Class: 70

Product Literature

• SlideDriver Product Brochure
• SlideDriver Installation Instructions (all models)
• SlideDriver Installation Instructions (Spanish)
• SlideDriver Programming & Operations Manual (all models)
• DC Power Supply Installation Instructions
